BM-603 3.2 Inch Popular Baby Monitor with Camera Video Baby Monitor





Name
Babynurse Camera/Baby Monitor
LCD Size
3.2″
Resolution Supported:
320 x 240
Receiving Sensitivity:
-90dBm
Consumption Current (Max.):
200mA
Battery:
Li-polymer / 750mAh,3.7V
Power Supply:
5V/500mA DC
CAMERA:

Image Sensor:
CMOS
Total Picture Pixels:
640 x 480pxl
Minimum Illumination:
0 Lux (IR on)
Night Vision Distance:
15 FT (5m)
Vision Angle:
45°
Power Consumption (Max.):
200mA
Power Supply:
5V/500mA DC

Specification:
1,Transmission Frequency: ISM 2400~2483.5 MHz
2,Transmission Power: 17dBm
3,Unobstructed Effective Range: 160ft/50m indoor/850ft/260m outdoor, line of sight
4,Spread Spectrum: AFH & TDMA
5,Modulation Mode: GFSK
6,Operating Temperature: 14 ~ 122° Fahrenheit/- 10 ~ +50° Celsius
7,Operating Humidity: <85%

MONITOR
1,LCD Size: 3.2″
2,Resolution Supported: 320 x 240
3,Receiving Sensitivity: -90dBm
4,Consumption Current (Max.): 200mA
5,Battery: Li-polymer / 750mAh,3.7V
6,Power Supply: 5V/500mA DC
7,Dimensions (W x H x D): 70mm x 120mm x 17mm 8,Weight: 0.08kg

CAMERA
1,Image Sensor: CMOS
2,Total Picture Pixels: 640 x 480 pxl
3,Minimum Illumination: 0 Lux (IR on)
4,Night Vision Distance: 15 FT (5m)
5,View Angle: Diagonal 45°
6,Power Consumption (Max.): 200 mA
7,Power Supply: 5V/500mA DC
8,Dimensions (W x H x D): 67mm x 106mm x 67mm 9,Weight: 0.1 kg


Package listing:

1* Monitor
1 * camera
1 * Power Adapter
1 * User Manual

Packaging: 18.50*15.00*7.20cm
Carton: 74*39*32cm, 10KG, 20pcs/carton
